Wheels & Tyres
Front/Rear Wheels
OZ Racing 17” light weight rims front and rear.
Front/Rear Tyres
DIABLO SLICK Front 125 / 75 R17. Rear 200 / 65 R17.
Engine
Triumph Triple 765cc liquid cooled, four-stroke. Special racing parts developed by Triumph.
Maximum Power
Over 145 HP (104KW)
Maximum Torque
Over 85 N.m
Maximum Speed
In excess of 300km/h
Exhaust
SC Project
Chassis
Frame
Aluminium twin spar, CNC machined, multi-adjustable steering geometry/ wheelbase/ride height.
Swinging Arm
Aluminium swinging arm, CNC machined, adjustable. Alternative rear suspensión links available.
Suspension
Öhlins upside down front forks and Öhlins rear shock, all adjustable for pre-load, compression and rebpund damping.
Brakes
Front Brakes
Disc latest double Brembo 305mm diameter with cooling fins. Caliper latest MotoGP caliper with cooling fins and cooling piston.
Rear Brake
Single 218 mm stainless steel rear disc, twin-piston caliper.
